Posted on Leave a comment

Renovation in Dehradun for Ajay Bisht Ji – Aman Vihar

We are getting all the projects with engineers only, don’t know whether this is good or bad. Ajay Bisht is an engineer by profession and we got the opportunity to work at his place. A client has come from Chandigarh that day, and madam came to discuss our for their house renovation and paid advance at the same time. Madam was clear about what she wanted. We are mentioning the scope of work in the below points.

  • The kitchen area had to be developed, the roof had to be extended there and the kitchen had to be developed on top of it.
  • There was an open terrace outside so there was a leakage issue, it had to be converted into a hall.
  • It was to be developed like a party hall which would have an open kitchen and a powder room.
  • Mussoorie view was not available from above, so the roof had to be extended and a deck type structure was made above so that the view could be obtained.
  • We had to do all the plumbing, tiles, masonry, fabrication and electrical work from start to end. This project was mostly in prefabrication.
  • Later, we also had to build an entry ramp for them. It was difficult as all this work had to be done during the rainy season.

It took us more time to complete the project because of the rain. We had the issue of leakage which wasted a lot of our time because the side wall was dead from the neighbour’s end and was getting wet again and again. This project was a low budget project, minimal expenditure was incurred in the project by using cost effective things. Photos and videos of the project will be available on our YouTube channel. We are also embedding a video below. Will upload photos soon.

Posted on Leave a comment

Solar Tin Shed for Upendra Singh Ji, Canal Road, Dehradun

Canal Road Tin Shed for Solar Panels designed in Dehradun. Projects Size 2600sqft, Production Time 20 Days

We have installed this tin shed on canal road Dehradun for Upendra Singh Ji. This is a tin shed of total 2600 sqft in which a 5 kilo watt solar panel will be installed on the south facing side of the upper shed. The shed has been designed with this strength in mind. Due to solar, the gap of its purlin had to be kept at 2.5 feet and we also kept the truss at a gap of 8 feet.

Specifications:

  • All structure hollow pipes by APL Apollo
  • Column – 100mm square, 16 gouge / 30kg, height 8.5ft
  • Ladder – 40mm square, 18 gouge / 9kg, height 1ft
  • Truss – 75mm by 40mm, 18 gouge / 13kg, height 3ft, Gap 8ft
  • Perlin – 40mm square, 18 gouge / 9kg, Gap 2.5ft
  • Red Oxide – Berger, twice
  • Paint – Enamel, Asian Paints, Double Coat
  • Sheet – .45mm JSW Color Coated, 7 Years Warranty, Color Grey, AZ70
  • Gutters – 5in by 5in square, .45mm, JSW White
  • Ridge – 16in, .45mm JSW Grey
  • Jhallar – 12mm, WPC, Density 6.5mm
  • Cost – Rs. 170/sqft
  • Project Duration – 20 Days
Canal Road Tin Shed for Solar Panels designed in Dehradun. Projects Size 2600sqft, Production Time 20 Days
Canal Road Tin Shed for Solar Panels designed in Dehradun. Projects Size 2600sqft, Production Time 20 Days
Canal Road Tin Shed for Solar Panels designed in Dehradun. Projects Size 2600sqft, Production Time 20 Days
Posted on Leave a comment

Prefabricated Cafe & Toilets at Greenfield Turf for Aman Rawat Ji

Project Details:

  • Area: Restaurant / Cafe – 26ft by 10ft & Toilets 16ft by 9ft
  • Footings: 450mm Ground clearance, 75mm by 75mm Hollow Pipe, 1.6mm Thickness
  • Platform Details: 100mm by 50mm hollow pipe, thickness 1.2mm, grid size 600mm sq. with 18mm cement fiber
  • Walls: Structure 50mm sq, 1.2mm thick hollow pipe grid 600mm x 1200mm, interior 10mm cement fiber, exterior .5mm liner sheet Z-black JSW 150AZ coating.
  • Roofing: MS checkered plate 3mm on MS Grid, 100mm x 50mm hollow pipe, 1.2mm thickness, grid sized 600mm sq.
  • Tiles: Kajaria 300mm sq on floor and 300mm by 600mm on walls.
  • Sanitary Fittings: Standard fittings with one peace english seat, washbasin in both kitchen sets.
  • Electrical: Havels HRFR Wiring with Havels Concealed lights and Polycab Switches.
  • Windows: MS Frame with 4mm sky-blue tinted glass.
  • Doors: MS Framed doors with same paneling sheet .5mm liner z-black.
  • Staircase: MS Staircase 250mm tread and 175mm riser.
  • Waterproofing: Bitumin Sheet 2mm with bitumin primer on top of checkered plate.
  • Extension Pergola: 26ft by 6ft pergola with 2mm polycarbonate transparent sheet.
  • Time: 3 months from start of construction.

Posted on Leave a comment

3000sqft Prefabricated Rooftop House for Ramesh Sharma Ji, Rishikesh

3200 sqft Tin Shed in Rishikesh Tapowan Uttarakhand

This post may be useful to you for prefabrication and light-weight construction. In this you can see how heavy water tanks and solar can be kept on top of the shed, we have completed this project on the banks of Ganga at Tapowan in Rishikesh which includes 3200sqft Tin Shed, 6000 liter water tank stand and 2000 liter solar geyser facility.

6000 Litre water tanks stand installed in Rishikesh Uttarakhand
6000 Litre water tanks stand installed in Rishikesh Uttarakhand
Water Solar Geyser Installed at Rishikesh Uttarakhand
Water Solar Geyser Installed at Rishikesh Uttarakhand
Water Solar Geyser Installed at Rishikesh Uttarakhand
Water Solar Geyser Installed at Rishikesh Uttarakhand

This is a prefab shed, in which prefabricated rooms will be made, in it all the pillars will be concealed in the brick. There will be gypsum ceiling at the bottom of the truss which will also have soundproofing and weatherproofing facility and will give the feel of a civil house, nowadays it is better to do prefabricated construction on the top level. According to the room layout these pillars have been cast. This is also easy because the pillar plate is welded to the column’s bar. The clear height of the shed was kept at 9.5ft and after ceiling the client would get a height of 9ft. Center height of shed is 12.5ft. In this, trusses have been placed at a gap of 10 feet.

Initially there was no confirmation of placing the solar overhead that the party had planned at the end moment, otherwise the truss in the solar wale shed is placed at a distance of 7ft and the backside part of the solar geyser is where the tank remains above it. it is very good. Solar geyser cost Rs. 60,000 per 500 liter in which 50% of your money is returned as subsidy, where 4 units are installed the cost is Rs. 2 lakh 40,000. Talking about the water tank stand here, this tank is of 1,000 liters and its stand is at least 160 sqft. it costs Rs. 8,000 per tank. There are 6 tanks here so this stand party costs Rs 50,000. We charged Rs. 170 per square feet for the shed, because access to material here is a bit costly and this work is done on the 3rd floor, otherwise our standard rate is Rs 150/per sqft. Our experience with Party was very good, we worked hard and made a lot of changes during the work, which was a bit difficult, but our expert welders handled the challenges well and completed this project.

The party also liked this work, he also got the glazing and elevation work done, the updated video of which we will put on the channel soon. All the material in it is APL Apollo 18 Gouge and the sheet applied on top of the shed is of .45mm JSW Brick Red color. Gutters are of white color which are specially customized because more than 1,000 sqft area water is coming in the gutter, for that there should be a gutter of at least 6in by 4in.

This project was completed in 1 month because the water tank stand was made by taking out pillars from the shed. You can see the height of the water tank in it, it is 7ft higher than the shed top level which can provide proper supply to the tank of the solar geyser installed on the shed and also maintain the water pressure.

Also keep this in mind, the distance from tank to tank should be at least 6ft, here the gap should be a little less, because the truss was at our place, we told you earlier also that there should be a gap of 7ft between the trusses to help and better. ho jata. You first decide whether to invest in solar future or not.

If you also want to get construction, renovation, interior work done in Dehradun or nearby cities, you can always contact us. Thank you for your time.

Posted on Leave a comment

900sqft Shed Roofing TATA for Mahesh Rawat Ji Dehradun

White Tata Tin Shed in Dehradun
In this we have given glazing on the side in which we have placed a glass openable. In this we have used 4mm glass with blue tint.
In this we have given glazing on the side in which we have placed a glass openable. In this we have used 4mm glass with blue tint.
The sheet is Tata brand Infinia whose thickness is .45mm. Minimum slope is given in it. The shade does not look good if it is given too much slope.
The sheet is Tata brand Infinia whose thickness is .45mm. Minimum slope is given in it. The shade does not look good if it is given too much slope.
PVC Downpipes Installed at Tata Tin Shed in Dehradun
In the tin shed, we have given PVC Gutters which are of Supreme brand. The shade sheet color is white and off white color is used on the structure.
Posted on Leave a comment

500sqft Pergola Roofing for Mahesh Barthwal Ji, Dehradun

Mukesh Barthwal ji is our client from Dehradun, he has built a floor above old construction for which we have done complete fabrication work. In this, first of all we increased the size of the balcony at the back of ground floor, it was very less we increased it from 2.5 feet to 5 feet. In the metal floor, we made grid of one and a half feet by 2 feet and welded a 3 mm metal sheet over it. On top of that, they put tiles.

Next we provided 3 feet by 1 feet steps in Staircase. In this, after four steps, we provided a ramp and then took Jeena straight to the terrace. It cost only ₹40,000 to the client and it was made into a complete Apollo MS hollow pipe.

After metal floor & staircase we installed the 3ft high railing on first floor and 1.5 feet high on the top floor. The design of CNC used which is connected to nature and is made of 3 mm MS sheet.

We advised Barthwal ji to reduce the cost of 80 rft railing which costing him ₹80,000, because the construction contractor can provide the parapet in the construction budget. So we ordered his contractor to give 1.5ft solid concrete parapet over the 1st floor roof. Then we installed the railing of 1.5ft high and that reduced the railing budget by 40%. It cost less money but looked better than the ground floor railing.

Barthwal ji wanted transparent Pergola on the front side so that his windows could be covered from rain and the elevation of his house could also be improved. For this, we gave them a cost effective solution in which polycarbonate 2 mm sheet were installed over 3/3 ft MS Grid. In this, hollow pipes of 3 inches by 1.5 inches were used and the pillars installed were 4 inches square.

Polycarbonate Pergola completed at Kargi Chowk, Dehradun for Mukesh Barthwal Ji. Area 370sqft, Sheet - 2mm Frosted Polycarbonate Sheet. Cost Rs. 275/sqft.
Polycarbonate Pergola completed at Kargi Chowk, Dehradun for Mukesh Barthwal Ji. Area 370sqft, Sheet – 2mm Frosted Polycarbonate Sheet. Cost Rs. 275/sqft.

At the front of the Pergola, we cut the pipe into the design to create tails and also installed gutters so that all the water can flow towards the staircase. This pergola cost the client ₹275 per square foot.

We have also provided Khaprail shed at left side balcony of the building. That is 34ft wide with 3.5 ft projection. We used .5mm Khaprail sheet with Gray Stone Finish. Cost of this raincover was ₹ 220 per sqft.

We are still working on the site. Stay connected with us for more such updates. Thank you.

Posted on Leave a comment

Pooja Mandir for Home in United States based client

Wooden Pooja Mandir for Home with Om Backdrop WPC with Hanging Bells

Recently we have exported the temple to America. In which the size was 6ft high and 4ft left. This temple is completely made of high quality material, in which century board and Marino laminate have been used. In this we have also given storage below and finalized the temple with the backdrop of Om.

Om Backdrop Pooja Mandir in United States New Jersey
Mandir Delivered in New Jersey USA

Details are given below:

  • Material:
    Structure – Century Club Prime Board 19mm
    Laminate – Marino 1mm Textured
    Handle – G Profile Hettich
    Fittings – Godrej
    Lights – Havels
  • Weight – 80kg

Delivery Time – 15 Working Days
Total Value: $1500 including shipping charges

Posted on Leave a comment

Soundproofing Options For Tin Shed Roof – Prefabrication

Shed roofing has become common in cities like Dehradun where it rains heavily. But there are some problems in it like it makes a lot of noise while raining, heats up a lot and security issue. Doon Projects is continuously working on these things and we are giving you some options so that you can get rid these problems.

There are 3 main solutions for sound proofing. Whose costing and look will be different.

  1. We have built many houses in the last few days, in which we put 6mm Cement Fiber Board on the framing of the shed and put sheets over it. You know Cement Fiber Board is a weather proof product and the thickness has been kept 6mm so that minimum weight comes on the shed framing structure. In this, 3in b 1.5in rafters have to be provided for purlin, whose weight ranges from 10kg to 13kg. Due to this there is no flexibility in the shed, so there is no crack in the ceiling below.
    Carpenter Taking size to install Flush Door at Prefabricated Room site
    Carpenter Taking size to install Flush Door at Prefabricated Room Site

    In this, the lower rafters are visible, on which you have to paint enamel, in this the lights are also installed on the walls only. You can’t even tighten the wiring of the lights and the slope of the roof also looks similar from below. Due to this, there is a difference of Rs. 30 per square feet in the price of shed.

  2. Gypsum Paneling Sheet is another material used for heatproof in tin sheds. Its sealing looks great, and removes all complications. Its 6ft by 4ft sheets come, which can be fitted on aluminum frame. All the wiring will also be done in it, the incandescent lights will also be installed and it remains cool. Talking about its cost, it will cost you around Rs.70 per square feet. If you go with the design then the cost can also increase. Below you can see the work of gypsum ceiling which we have done on Rajpur road.
  3. The third and cheapest option is grid ceiling, in which a grid of 2ft by 2ft is made. Gypsum sheets or Therma-coal are used in this and it costs Rs.45 per square feet. It is suitable for office, its look is cheap at home, if you want, you can do PVC ceiling by keeping Therma-coal on top.

We will keep updating you in future. subscribe our Youtube channel, And contact us for any interior, fabrication or renovation work in Dehradun. CALL AT 7060504666.

Posted on Leave a comment

Radha Krishna CNC Mandir for Dehradun Based Client

Radhe Krishna Mandir for Dehradun Based Client

We have built this temple for a client living on Sahastradhara Road in Dehradun. It took us 10 days to build this temple, the client gave a lot of feedback and all the credit goes to him for the beauty of the temple. Its height is 7 feet and width is 40 inches. One can worship while standing in it, its base cabinet height is 3.5ft. We have created it with soft close (Godrej) accessories. The laminate is from an advanced company and the board is made of mix material.

Pooja Mandir with Glowing Shelfs
Pooja Mandir with Glowing Shelfs
Wooden Look Pooja Mandir Standing Look
Wooden Look Pooja Mandir Standing Look

Mix means aluminum sheet (ALEX) is used in the back side, base cabinet is made of HDHMR (Ation TESA) and painted with DUCO over it by applying WPC 18mm in the mesh. Lights have also been used in the temple in a good way, lights have been given below all the shelves. We have satisfied the client and fixed at home. The client is very happy in his temple, we are very greatful to do this project.

If you are looking for any interior, construction or renovation project in Dehradun you may visit us on Sahastradhara Road, or contact our team at 7060504666.

Posted on Leave a comment

2560sqft Tin Shed Balawala, Dehradun for RS Negi Ji

We have made this tin shed at Balawala, Dehradun under the supervision of a senior engineer. We have welded directly on the bars of RCC columns, which has resulted in the most stable structure we have ever come across. Its area is 50ft by 50ft and in future, Negi ji is going to make prefabricated rooms with bison panels under it.

Ladder is fixed on the top of Main Pillars
Rafters is being installed
Leveling the Truss
Truss being installed
Truss is being fixed at the top of Ladder
Truss has been made
Gutter installation done, sheet installation in progress
JSW .45mm sheet in process
Side view of mumty and main shed
Purlin structure view of tin shed
Mumty shed has been kept 4ft down from main shed.
Side view of ladder and gutter.

All gutters have been joined with PVC Pipes
Final PVC Plumbing work and waterproofing is being done
Front Side Truss View of Tin Shed with Plain White Sheet
Front view of tin shed

The truss in the structure is fixed on the ladder (Hollow Pipes 1.5in square, Height 12in), so that the structure can get double strength, Each truss has 2 support pillars (Height 8ft, Pipe 4in Square Hollow Tubes) at the bottom at a gap of 12.5ft. All material is branded (APL Apollo Pipes) and Red oxide treated to leave no chance of rusting, whatever welding work has been done, the covering has been done immediately.

Special care has been taken in the finishing, work has been done by our finest craftsmen (Ahtesham – Fabrication, Danish Khan – Plumbing and Electrical, Lalit Kumar – Paint, Bhupendra – Red Oxide Treatment). The paint is all white (Asian Paints), done with an enamel electric paint gun, we installed the sheets immediately after the paint. Here we have used JSW .45mm material, the gutter has been kept white and all other colors have been kept red. This combination suits every home. The center height of the shed is 12ft and the side height is 8ft. The front and back side trusses are covered with plain sheets (JSW Plain White .45mm), the additional cost of which is Rs. 60. The top of the stairs in the shed is made 4 feet down so that water does not come from the sides. But on top of that 3ft overlapping of top shed has also been done. Silicon sealant is applied on all gutter joints. Gutter has been holded by 1in by 3mm patti with help of Metal Screws.

All the two pipes and plumbing work has been done by our team only. The shade is very nice, the party is also very happy to see the end result. In payment terms, we have given advance 50% structure, after that 30% for the sheets on completion of the structure and 20% after completion. The work has been done very satisfactorily, so it took 3 weeks for this work. If you also want to do any fabrication, interior or renovation work in Dehradun, then you can contact us, Our workshop is located at Mandakini Vihar, Sahastradhara Road. You can also contact us on 7060504666. Thank you for your time.
